MEG (Motionless Electromagnetic Generator)
by Tom Bearden, Stephen Patrick, James Hayes, Kenneth Moore, James Kenny · USA
Safety & Liability Disclaimer
Replicating alternative electromagnetism or mechanical resonance systems carries extreme physical hazards including lethal voltage shock, explosive gas ignition, mechanical shrapnel, and chemical toxicity. All contents, schematics, and guidelines on this page are provided strictly for educational and historical research.
By viewing or constructing any design herein, you agree to assume 100% of all risks and to indemnify and hold harmless the site owners, authors, and contributors. Read our complete, legally binding Safety & Liability Disclaimer.
Overview
A permanent magnet and multi-path ferromagnetic core with input and output coils. By alternately pulsing the input coils, the permanent magnet's flux is redirected through different paths in the core, inducing current in the output coils. Claims to tap zero-point/vacuum energy. No moving parts.
⚖️ What Would Convince Us?
To validate the anomalies claimed for this device under mainstream scientific parameters, builders and inventors must document and present evidence satisfying the following criteria:
Closed-loop operational testing proving net-positive work output
Calibrated calorimetry auditing tracking total heat dissipation
Independent replication by an unaffiliated research laboratory
Investigation & Credibility Metrics
Sources are not verified or currently undergoing archive indexing.
Claimed overunity/propulsion has not been verified in a control lab.
No third-party replication attempts have been documented.
No measurement details or instrumentation list were provided.
This device is purely open-source or historical; no active sales.
How It Works
A permanent magnet creates a static flux field through a toroidal or multi-path core. Input coils momentarily divert this flux from one path to another. As the flux switches paths, it passes through output coils and induces EMF. The input energy only needs to 'switch' the path, not create the flux — the permanent magnet provides the primary flux for free.
History & Background
One of the only 'free energy' devices with a GRANTED US patent (US 6,362,718, March 2002). Jean-Louis Naudin at JLN Labs published extensive replication documentation and reported COP ~1.76 in certain configurations. Despite the patent and multiple claims, no commercial unit was ever produced.
Community Status
The granted US patent provides legitimacy and detailed engineering specs. Naudin's open-source replication docs are excellent starting points. Critics point to measurement methodology flaws and note the patent doesn't validate the physics claims.
🔧 Build Guides
⚠️ CRITICAL SAFETY WARNING
DANGER: LETHAL VOLTAGE, EXPLOSIVE GASES, AND HIGH-VELOCITY PROJECTILES.
This document is a historical archive of unverified claims, NOT a set of instructions. Enmagx and its creators take zero responsibility for injury, death, or property damage resulting from attempting to replicate these theoretical devices.
Proceed for historical research purposes only. Do not attempt to build without professional engineering supervision.
📺 Video & External References
🔗 Step-by-Step Construction Guides & Forums
Jean-Louis Naudin's detailed logs detailing toroid core gap routing and switching circuitry.
Full-text patent filings showing flux-steering coil overlays and core configurations.
📖 Patrick Kelly Guide: Technical Assessment
Chapter 3 REFERENCE
Figure: MEG (Motionless Electromagnetic Generator) schematic layout from Patrick Kelly\'s Guide⚠️ Unverified or Disputed Media Archive
The following media assets associated with this device have low verification confidence, lack clear copyright licensing, are AI-generated, or are contextually disputed.
🤖 AI GENERATEDHistorical rendering of the meg.
Reported Source: Local Generated Media Archive
License: FAIR_USE (COMMENTARY_ONLY)
Discussions
View all →No discussions yet. Be the first to start one!
🔧 Key Components
- •Nanocrystalline or grain-oriented silicon steel core (multi-path)
- •Strong permanent magnet(s)
- •Input coils (low inductance switching)
- •Output coils (power extraction)
- •MOSFET switching circuit
- •Timing/oscillator circuit
- •Measurement equipment
